4-Channel AI Intelligent 4G Dash Camera, ADAS + DMS + BSD Active Safety,1080P+720P Recording for Taxis

Shenzhen Vanwin Tracking Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

4-Channel AI Intelligent 4G Dash Camera, ADAS + DMS + BSD Active Safety,1080P+720P Recording for Taxis

AV Inputs : 2CH/4CH

Chinese Voice Control : Support (optional)

MOQ : 1pc

Delivery Time : 2-3 days for samples,15-30 days for large orders

Video Input : Built-in 2ch, external 2ch 720P

Model Number : VW-T658AI

Storage Capacity : Max. 256GB

Loop Recording : Yes

Dimensions : 90mm x 54mm x 36mm

Payment Terms : T/T or western Union or Paypal

View Angle : 120 Degree

Route History : Yes

Price : negotiated

Storage Type : MicroSD card (up to 128GB)

Cpu : MSTAR(MSC8336)

Supply Ability : 5,000pcs per month

Product Features : AI 4G Dash Camera

Brand Name : Vanwin Tracking

Lens Angle : 170 degrees wide angle

Video Format : H.264

Certification : CE/FCC/RoHS

Resolution : 1080P, 720P

Place of Origin : Shenzhen,China

Working Temperature Range : -20 - 70 ℃

Packaging Details : Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs .

Contact Now

4-Channel AI Intelligent 4G Dash Camera, ADAS + DMS + BSD Active Safety,1080P+720P Recording for Taxi

Product Overview:

Secure your vehicle, protect your passengers, and safeguard your business with this advanced AI Smart 4G Dash Camera, specifically designed for the unique needs of taxis, ride-sharing (Uber/Lyft), and private vehicles. This compact, intelligent telematics device provides dual-channel high-definition video recording (front and in-cabin), proactive AI driver monitoring, and real-time 4G connectivity, offering an all-in-one solution for safety, security, and liability protection.

Key Features & Benefits:

  • Dual-Channel Complete Coverage:

    • Simultaneously record the road ahead in crisp 1080P HD and the vehicle cabin in clear 720P HD, providing irrefutable video evidence of accidents, passenger disputes, or incidents inside the car.

    • Utilizes advanced H.265 & H.264 encoding to deliver high-quality footage while optimizing storage efficiency.

  • AI Driver Monitoring System (DMS) for Active Safety:

    • Uses an in-cab camera with a built-in high-performance NPU (neural network engine) to intelligently detect and alert for unsafe driving behaviors in real-time.

    • Includes alerts for: Fatigue Driving, Smoking, Phone Usage, Distraction, and Occlusion (blocking the lens).

    • Benefit: Protects your passengers and driver by preventing accidents before they happen.

  • Always-On 4G & GPS Connectivity:

    • Global 4G LTE: Features a built-in 4G module that supports global frequency bands for stable, worldwide operation.

    • GPS + Beidou Dual-Mode: Embedded high-precision positioning modules provide accurate, real-time vehicle tracking, historical route playback, and location data for dispatching or proof of service.

    • WiFi Hotspot: Built-in 2.4G WiFi allows passengers to connect to the internet (optional feature) or enables easy connection to your smartphone for configuration and video viewing.

  • Designed for Taxis & Private Cars:

    • Wide Input Voltage: Supports DC +10V ~ +36V, making it compatible with the electrical systems of virtually all passenger cars and taxis without requiring special adapters.

    • Compact & Discreet: An unobtrusive design that does not obstruct the driver's view.

    • Data Integrity Protection: Features a "TF Card + Super Capacitor" redundant design. The super capacitor ensures that the last recorded video file is completely and safely written to the storage card in the event of a sudden power failure during an accident, preventing critical data loss.

  • Smart Management & Emergency Features:

    • Two-Way Voice Communication: Built-in speaker and microphone support real-time voice intercom between the dash camera and a remote platform (useful for fleet dispatch or emergency assistance).

    • One-Key SOS Emergency Alarm: Includes an SOS button that the driver can press in an emergency to trigger an immediate alarm and alert the platform or owner.

    • Ample Storage: Supports one TF card slot (up to 512GB) for extensive local storage.

    • Easy Maintenance: Supports TF card and OTA (Over-the-Air) remote firmware upgrades.

Specification Parameters

ITEM Technical Specifications
CPU

Dual-Core processor@1.5GHz,Total coding resources 1080p*100fps

NPU@1.0TOPS neural network acceleration engine

Memory 2Gb DDR3
Video Input Active Pixels: 1920×1080,1080×720; H.264&H.265 format
2-ch Built-in CMOS camera, Low illumination 0.01LUX
2-ch External camera, AHD 720P@25fps
Video Output Not support,Support mobile APP preview and setting
Audio input / output Built-in MIC and speaker, G.711a format
Video recording resolution 1080P/720P/D1*25fps,Simultaneous recording of sound and video.
G-Sensor Built-in 3-axis acceleration
External interface 2-ch RS232, reserved for communication with peripherals
Alarm Input 2-ch sensor input,
Positioning module Built-in GPS / Beidou Positioning Module
4G built-in 4G module,TDD-LTE, FDD-LTE
WIFI Built-in, 2.4G,802.11b/g/n,STA or AP mode
TF Card Support 1 TF card, Support 16G/32G/64G/128G/256GB/512GB
USB Micro USB interface
Upgrade TF card and OTA
AI - ADAS Lane departure, collision alarm, Distance detection, pedestrian detection etc
AI - DSM Fatigue driving detection, Smoking, call mobile phone, Occlusion, Unsafe driving behavior habit detection
AI - BSD Blind area detection
Input voltage DC:+10V ~ +36V
Power consumption Normal working state < 5W (without external equipment)
Power off protection Super capacitor design, support abnormal power failure, ensure the integrity of video files
Working Temperature -25℃ to +70℃
Working relative temperature 20% to 80%
Equipment size 138mm*85mm*45mm
Net weight 0.4kg

Applications:

  • Ride-Sharing (Uber, Lyft, Didi, etc.): Provide undeniable proof in passenger disputes and protect driver ratings.

  • Taxi Fleets: Enhance passenger safety, monitor driver behavior, and secure assets.

  • Driving Schools: Monitor student performance and ensure instructor safety.

  • Private Vehicles & Family Cars: Add a high-level security and monitoring system for peace of mind.

4-Channel AI Intelligent 4G Dash Camera, ADAS + DMS + BSD Active Safety,1080P+720P Recording for Taxis
4-Channel AI Intelligent 4G Dash Camera, ADAS + DMS + BSD Active Safety,1080P+720P Recording for Taxis
4-Channel AI Intelligent 4G Dash Camera, ADAS + DMS + BSD Active Safety,1080P+720P Recording for Taxis
Frequently Asked Questions
1. Do you provide the free CMS?

Yes, is free of charge. We will provide you the authorized code after you buy our equipment.

2. What is the minimum requirement to run this software?

CPU 2.5G four core; Memory 8GB; HDD 1TB;

3. After we build our own server, can the IP of units be changed remotely?

Actually we can provide the protocol package for you to develop your own CMS. You could remotely change the settings of your vehicles, this is no problem.

Any further questions, please don't hesitate to contact us, we are very pleased to help you.
